HSM 904S

The 904S – professional – productive – reliable.

Technical data

Engine:
  • VOLVO PENTA
    TAD581VE EU Stage V
    Power: 129 kW (175 HP) from 1700 rpm
    Max. revolution: 800 Nm from 1100 - 1500 rpm
    Max. torque: 816 Nm at 1380 rpm
    Displacement: 5,13 liters

    Optional:

  • VOLVO PENTA
    TAD583VE EU Stage V
    Power: 175 kW (238 HP) from 1750 rpm
    Max. revolution: 947 Nm from 1200 - 1750 rpm
    Max. torque: 969 Nm at 1380 rpm
    Displacement: 5,13 liters
Transmission:
  • HSM High Speed Drive (series 71)
  • 2-step NAF transfer gearbox
Axles:
  • NAF heavy duty planetary axles
  • 100 % selectable differential locks
Brake:
  • 2-circuit brake, wet disk brakes
  • Spring-loaded parking brake
Steering:

  • 44° articulated steering

Tyres:
  Size: min. total width
Series: 23,1 x 26 2550 mm
Optional: 18,4 x 26 2300 mm
  28L-26 2750 mm
Tank capacity:
  • Diesel: 185 l
  • Hydraulics: 90 l
  • AdBlue: 45 l
Hydraulic system:

  • Pump output:
    Flow rate: 152 l/min at 1600 rpm
    Pressure: up to 350 bar

  • Hydraulic liquid:
    Series: HLP-46 mineral oil
    Optional: Panolin HLP SYNTH with Kleenoil
    Microfiltration WGK 1

Cabin:
  • Rubber-mounted, soundproofed
  • Tested safety cab
  • Mechanically suspended comfort seat
  • Hot water heating
Electrics:
  • 110 A (28 V) generator
  • 2 maintenance-free dry-cell batteries
Instruments:

  • Tachometer with operating hour counter, coolant temperature, tank gauge, indicator lights

Winches:
  • Series:
    Adler HY 20-O (2 x 100 kN) double-drum winch
    Max. cable take-up 14 mm, 100 m
    without cable equipment!

  • Optional:
    Adler HY 24-O (2 x 120 kN) double-drum winch
    Max. cable take-up 14 mm, 140 m
    Adler HY 24-LO (2 x 120 kN) double-drum winch
    Max. cable take-up 14 mm, 190 m
    Adler HY 32-O (2 x 160 kN) double-drum winch
    Max. cable take-up 14 mm, 150 m
    Adler HY 32-LO (2 x 160 kN) double-drum winch
    Max. cable take-up 14 mm, 190 m
    TCM 16+ (2 x 160 kN) double-drum winch
    Max. cable take-up 14 mm, 220 m
Weight:

  • 10.800 kg (series)
    Weight distribution:
    Front axle: 60 %
    Rear axle: 40 %

Standard equipment:
  • 2200 mm wide front polder shield, lowerable straight shield 2200 mm wide, fire extinguisher, first-aid kit, warning triangle, tool set
Special equipment:

  • Radio control, cable winch, wireless driving, clamping arms for front shield, steering with joystick, street lighting set
